ASUS MB Sc LGA1700 PRIME B760M-K DDR4, Intel B760, 2xDDR4, 1xHDMI, 1xVGA, mATX

Name: ASUS MB Sc LGA1700 PRIME B760M-K DDR4, Intel B760, 2xDDR4, 1xHDMI, 1xVGA, mATX
Brand: Asus
SKU: 431947
Price: 3649 CZK
Availability: InStock

Kód: 431947Prodejní číslo: 90MB1DS0-M0EAY0

Výrobce: Asus

Zdarma

ASUS MB Sc LGA1700 PRIME B760M-K DDR4, Intel B760, 2xDDR4, 1xHDMI, 1xVGA, mATX

+ 2
dalších

Popis

Parametry

Diskuze

Hodnocení

Detailní popis produktu

ASUS MB Sc LGA1700 PRIME B760M-K DDR4, Intel B760, 2xDDR4, 1xHDMI, 1xVGA, mATX

PRIME B760M-K D4

TECHNICAL SPECIFICATIONS

CPU	Intel® Socket LGA1700 for 13^th Gen Intel® Core™ Processors & 12^th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
	Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
	* Refer to www.asus.com for CPU support list.
	** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset	Intel® B760 Chipset
Memory	2 x DIMM, Max. 64GB, DDR4 5333(OC)/5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*
	Dual Channel Memory Architecture
	Supports Intel® Extreme Memory Profile (XMP)
	* Supported memory types, data rate(Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.
Graphics	1 x VGA port
	1 x HDMI® port**
	* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
	** Supports 4K@60Hz as specified in HDMI® 2.1.
Expansion Slots	Intel® 13^th & 12^th Gen Processors
	1 x PCIe 4.0 x16 slot
	Intel® B760 Chipset
	2 x PCIe 4.0 x1 slots
	Note: To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
Storage	Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
	Intel® 13^th & 12^th Gen Processors
	M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
	Intel® B760 Chipset
	M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
	4 x SATA 6Gb/s ports
	* Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.
Ethernet	1 x Realtek 2.5Gb Ethernet
USB	Rear USB (Total 6 ports)
	4 x USB 3.2 Gen 1 ports (4 x Type-A)
	2 x USB 2.0 ports (2 x Type-A)
	Front USB (Total 5 ports)
	1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
	2 x USB 2.0 headers support 3 additional USB 2.0 ports
Audio	Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback
	Audio Features
	- Audio Shielding
	- Premium audio capacitors
	- Dedicated audio PCB layers
	* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Back Panel I/O Ports	4 x USB 3.2 Gen 1 ports (4 x Type-A)
	2 x USB 2.0 ports (2 x Type-A)
	1 x VGA port
	1 x HDMI® port
	1 x Realtek 2.5Gb Ethernet port
	3 x Audio jacks
	1 x PS/2 Keyboard/Mouse combo port
Internal I/O Connectors	Fan and Cooling related
	1 x 4-pin CPU Fan header
	1 x 4-pin Chassis Fan header
	Power related
	1 x 24-pin Main Power connector
	1 x 8-pin +12V Power connector
	Storage related
	2 x M.2 slots (Key M)
	4 x SATA 6Gb/s ports
	USB
	1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
	2 x USB 2.0 headers support 3 additional USB 2.0 ports
	Miscellaneous
	2 x Addressable Gen 2 headers
	1 x Aura RGB header
	1 x Clear CMOS header
	1 x COM Port header
	1 x Front Panel Audio header (AAFP)
	1 x S/PDIF Out header
	1 x Speaker header
	1 x SPI TPM header (14-1pin)
	1 x 10-1 pin System Panel header
Special Features	ASUS 5X PROTECTION III
	- DIGI+ VRM
	- LANGuard
	- Overvoltage Protection
	- SafeSlot Core
	- Stainless-Steel Back I/O
	ASUS Q-Design
	- Q-DIMM
	- Q-LED Core
	- Q-Slot
	ASUS EZ DIY
	- ProCool
	ASUS Thermal Solution
	- VRM heatsink design
	Aura Sync
	- Aura RGB header
	- Addressable Gen 2 headers
Software Features	ASUS Exclusive Software
	Armoury Crate
	- Aura Sync
	- Fan Xpert
	- Power Saving
	AI Suite 3
	- DIGI+ VRM
	- PC Cleaner
	ASUS CPU-Z
	Norton 360 Deluxe (60 Days Free Trial)
	WinRAR
	UEFI BIOS
	ASUS EZ DIY
	- ASUS CrashFree BIOS 3
	- ASUS EZ Flash 3
	- ASUS UEFI BIOS EZ Mode
BIOS	128 Mb Flash ROM, UEFI AMI BIOS
Manageability	WOL by PME, PXE
Accessories	Cables
	2 x SATA 6Gb/s cables
	Miscellaneous
	1 x I/O Shield
	2 x M.2 anchors
	Documentation
	1 x User guide
Operating System	Windows® 11, Windows® 10 64-bit
Form Factor	mATX Form Factor
Form Factor	9.6 inch x 8.3 inch (24.4cm x 21.1cm)

Parametry produktu

COM port	Ano
Socket (patice)	Socket 1700
Formát základní desky	micro ATX
Chipset	Intel B760
Technologie paměti RAM	DDR4
PCI Express x16	1
3.5mm Jack	Ano
Pro procesory	Intel
Počet paměťových slotů	2
DisplayPort	0
TPM	Ano
M.2 slot	2
SATA 3	4
VGA	1
DVI	0
HDMI	1
PCI Express x1	2
DisplayPort Type-C	0

Více parametrů

Méně parametrů

Parametry produktu

COM port	Ano
Socket (patice)	Socket 1700
Formát základní desky	micro ATX
Chipset	Intel B760
Technologie paměti RAM	DDR4
PCI Express x16	1
3.5mm Jack	Ano
Pro procesory	Intel
Počet paměťových slotů	2
DisplayPort	0
TPM	Ano
M.2 slot	2
SATA 3	4
VGA	1
DVI	0
HDMI	1
PCI Express x1	2
DisplayPort Type-C	0
